Walrus Audio Canvas Volume Pedal

Walrus Audio Canvas Volume – Fully analog VCA volume pedal with contactless position sensing

Fully analog VCA signal path · Contactless sensor (no strings/pots/gears) · 8 tapers · Minimum On · Gain up to +9 dB · Lag up to 2s · Mono/Stereo/Dual Mono · Tuner Out · USB-C firmware

The Walrus Audio Canvas Volume is built for players who rely on a volume pedal as a real performance tool: precise control, true reliability, and flexible routing for nearly any rig. Its core idea is to remove the classic failure points of traditional volume designs — no strings, no pots, no gears. Instead, it uses contactless position sensing and high-quality analog VCAs to deliver smooth, musical volume changes with a fully analog signal path and consistent response night after night.

It’s not just about durability — it’s about feel. A discreet interface under the heel (two buttons and LEDs) lets you dial in four key parameters: Taper, Minimum On, Gain, and Lag. This means you can match the sweep to your playing style, keep swells from disappearing entirely, or even use the pedal as a clean volume boost without altering your tone.

Routing is designed to drop into almost any setup: mono, stereo, or mono to dual mono, plus a dedicated Tuner Out when running a mono rig.

Key features

• Fully analog signal path using high-quality VCAs

• Contactless position sensor: no strings, pots, or gears (nothing to wear out)

• Rugged steel/aluminum chassis built for stage and studio

• Flexible routing:

  • Mono In / Mono Out with dedicated Tuner Out

  • Stereo In / Stereo Out

  • Mono In / Dual Mono Out

• Under-heel customization: Taper, Minimum On, Gain, Lag

• 8 tapers: one Canvas taper + seven modeled from classic real-world pedals

• Minimum On: down to approx. −90 dB attenuation at heel-down

• Gain: unity (0 dB) up to +9 dB in 3 dB steps (clean boost use)

• Lag: immediate response up to 2 seconds for smoother swells

• Utility menu: Factory reset, calibration, mono mode selection, DFU (support-directed)

• USB-C firmware updates via walrusaudio.io

Technical specifications

• Power: 9V DC, 300 mA, center negative, 2.1 mm (PSU not included)

• Input impedance: 1 MΩ

• Output impedance: 330 Ω

• Frequency response: 20 Hz – 20 kHz

• Inputs: 2 × 1/4″ unbalanced TS

• Outputs: 2 × 1/4″ unbalanced TS

• USB-C: firmware updates via walrusaudio.io

• Size: H 4.8 cm × W 9.1 cm × D 22.5 cm

• Weight: 1.0 kg

• Origin: USA

• Color: Black

• Type: Volume pedal

• Brand: Walrus Audio

Find the Walrus Audio Canvas Volume and a carefully curated selection of boutique pedals at onemorepedal.com, your specialist store for high-end effects.

A volume pedal designed to outlast the problems it replaces.
